This machine is suitable for weaving natural fibre (cotton,wool, hemp), silk, synthetic fibre, chemical fibre and blending yarn etc.
Jeans, bed sheet, and other heavy fabric can be weave.
With stronger frames and improvement of the betting - up, special weft insertion device make - 736 loom more special, easy to achieve higher speed and able to weave thicker fabrics than any other imported and domestic rapier loom
Technical Data:
| Reed width |
200, 230, 250, 280 cm |
| Speed |
200-250 r.p.m |
| Yarn range |
Fabric with natural, artificial, silk, synthetic & blended yarn, weight from 15 to 550 g/m2 |
| Power |
1.5 kw main motor |
| Shedding |
Upper mechanical dobby |
| Weft selection |
4-6 colours (Mechanical) |
| Let-off motion |
Adopting friction type let-off |
| Warp stop |
6 - 8 rows electric warp stop |
| Electric control |
By micro computer control |
| Weft stop |
Piezoelectric ceramic sensor control weft stop |
Optional:
-
Electronic dobby, Mechanical / Electronic Jacquard
-
Tuck-in-deivce for selvedge
-
8 colour Mechanical / Electronic weft selector
|
