Durable and widely use for all type of fabrics.
Cost-effective, low to high quality yarn can weave.
Less maintenance.
Maximum productivity.
Technical Data:
| Reed width |
150, 180, 200, 230, 255, 280, 320, 340, 360 cm |
| Speed |
200 r.p.m, Max. inserting rate:400 m/min. |
| Fabric weight |
70-450 g/m2 |
| Power |
1.5 kw main motor |
| Shedding |
Upper mechanical dobby, spring reversing
motion, maximum 20 heald frames |
| Rolling-up |
Mechanical interval rolling up ranging from
6 roots to 60 weft/cm |
| Warp stop |
6 roes electric warp stop motion |
| Weft stop |
Piezoelectric sensor, with high sensitivity |
| Weft selection |
Controlled by dobby, single, multi-colour,
max. 6 colours |
Optional:
-
Electronic dobby, Mechanical jacquard
-
Electronic weft selector up to 6 colours
-
Tuck-in-device for selvedge
|
