For Plain weave only.
Durable and widely use, composite slay beating-up motion.
Not less than 400m/minute and high quality yarn can weave.
No qualified worker needed.
Technical Data:
| Reed width |
150, 180, 200, 230, 255 cm |
| Speed |
200 r.p.m, Max. inserting rate : 400m/min |
| Yarn range |
Cotton 6Ne-80Ne, Wool 10Nm-135Nm,
Chemical Fiber 900D-70D & Silk 20Dn-500Dn |
| Fabric weight |
70-450 g/m2 |
| Power |
1.5 kw main motor |
| Shedding |
Tappet motion |
| Let-off |
Outside mechanical interval let-off, ranging
from 6 roots to 60 roots/cm |
| Rolling-up |
Mechanical interval rolling-up, ranging from
6 to 60 weft/cm |
| Weft stop |
Piezoelectric sensor with high sensitivity |
| Warp stop |
6 roes electric warp stop motion |
Optional:
|
